The so-called narrowband filter is a subdivision of the bandpass filter, and its definition is the same as that of the bandpass filter. This type of filter allows light signals to pass through a specific frequency band, while blocking light signals on both sides that deviate from this band. The passband of a narrowband filter is relatively narrow, generally less than 5% of the center wavelength value.
The main function of narrowband filters is to allow specific wavelengths of light to pass through and reflect (or attenuate) other wavelengths of light as optical components. The half wave width is usually controlled at 20nm or less, and there are ultraviolet, visible, near-infrared, near-infrared wavelengths, and far-infrared bands according to the wavelength range. Our company's narrowband filter is made of multi-layer hard film deposited with ion assisted nano materials by high vacuum evaporation, with good film density and high imaging clarity.
Product advantages:
◆ Hard coating, service life
◆ Accurate wavelength positioning
◆ Ion source assisted plating, low temperature drift
◆ High penetration rate
◆ High cut-off depth
Product specifications:
窄带滤光片波长：365nm、380nm、394nm、405nm、420nm、430nm、440nm、450nm、465nm、470nm、490nm、520nm、532nm、546nm、550nm、560nm、570nm、580nm、590nm、600nm、620nm、635nm、648nm、654nm、660nm、670nm、690nm、720nm、740nm、460nm、780nm、808nm、810nm、830nm、845nm、850nm、860nm、870nm、880nm、905nm、940nm、980nm、1000nm、1050nm、1064nm、1080nm、1200nm、1550nm
Application areas:
Fluorescence analyzer, enzyme-linked immunosorbent assay (ELISA) reader, cable TV upgrade equipment, wireless transmission equipment, mobile barcode scanning, infrared electronic whiteboard, infrared camera, infrared touch screen, iris recognition, infrared medical instrument, infrared ink recognition, red film recognition, facial recognition sensor system, handheld infrared laser rangefinder, laser rangefinder, optical instrument, medical and health equipment and detection instruments.
